Features
Water-proof design with IP-65 Protection level.
Integrated with flap-up splice trays and adapter holder.
Maximum 120F splice capacity, stainless anti-rust bolts and nuts.
Easy for maintenance and expansion.
Fiber bend radius control more than 40mm.
180 degree access with buckled lock structure.
1*8 or 1*16 PLC Splitter can be installed in each splice tray as option.
16 pcs of mechanical por ts for 3-7mm drop cable.
1 mid- span cable entrance(10-16.5mm) for uncut cable and 2 reser ved cable entrances for distribution cable gland(8-13.5mm).
Configuration
| Material |
Size |
Max Capacity |
Numbers of Adapter |
Weight |
Color |
| PC+ABS |
L*W*H(mm)
340*220*95 |
Splice 120 Fibers
( 5trays x 24F) |
PLC Splitter
2pcs of 1x8(SC) |
24 pcs SC/UPC or SC/APC |
1.85kgs |
Grey/Black |
